The RB260GS is a low-power SOHO switch. An Atheros Switch Chip powers five Gigabit Ethernet ports and one SFP cage.
S-85DLC05D, S-31DLC20D, and S-35/53LC20D MikroTik SFP modules have been tested and recommended for use (not included)
SwOS is an operating system created exclusively for MikroTik Switch devices.
SwOS can be configured using your web browser. It provides all of the essential functions of a managed switch, plus more: Allows you to control port-to-port forwarding, use MAC filters, set up VLANs, mirror traffic, set bandwidth limits, and even change specific MAC and IP header information.
01
5 Ethernet ports and 1 SFP port for fast wired and fiber connections.
02
Supports VLANs, traffic control, and easy web-based management.
03
Passive PoE and DC jack (11–30 V) with low energy use (~5 W).
04
Fanless design ensures quiet and reliable operation for small offices.
The MikroTik RB260GS, with product code CSS106-5G-1S, is a compact networking device with dimensions of 113 × 139 × 28 mm, running on the MikroTik SwOS operating system. It features 128 KB of FLASH storage and has been tested to operate in ambient temperatures ranging from -20°C to 70°C, with the suggested price available upon request. For powering, the MikroTik RB260GS supports Passive PoE with an input voltage of 11–30 V and includes two DC inputs, PoE-IN and a DC jack, both supporting 11–30 V, with a maximum power consumption of 5 W. On the Ethernet side, the device provides 5 Gigabit Ethernet ports supporting 10/100/1000 Mbps for high-speed connectivity. For fiber networking, the MikroTik RB260GS includes one SFP port with SFP DDMI support, ensuring monitoring and compatibility for fiber connections.
